Product Description

• Sloped top design,
• Available with amber or clear vials.
• Available with 20ml or 10ml vials.
• Suitable magnetic aluminum caps for CTC instruments.
• Butil/PTFE, Pharma-Fix-Liner (Butil/PTFE), Silicon/PTFE all available.
• Round or flat bottom profiles available for proper instrument compatibility.
• 20mm Aluminum and Magnetic Aluminum capped, 6ml curved headspace vial matched with 20mm PTFE/rubber septa.
• Curved top Aluminum Cap, 10mm Center Hole for 6ml vial.

Features

• Curved caps consistently provide a secure seal.
• Sloped top for maximum secure seal.
• 45 psi pressure relief cap option.
• 10/20mL Clear/Amber Precision Curved Head Vial, Flat/Round Bottom, 22.5*46mm.
• PTFE/Silicon Septa Φ20*3mm Temperature Resistance -60℃-200℃ with 9mm thread.
• Curved Top Aluminum Cap, 10mm Center Hole Φ20mm.
• Curved Top Blue Magnetic Aluminum Cap, 10mm Center Hole Φ20mm available.

About 6mL Vials:

• 6ml curved vials, 22*38mm.
• Suitable for Metrohm instruments.

20mm Head Curved Vials

Part No.	VH2017 (Economy)	VHR2017 (Economy)	VH2035	VHR2035
Description	20mL Clear Curved Top Head Vial, Flat Bottom, 22.5*75.5mm	20mL Clear Curved Top Head Vial, Round Bottom, 22.8*75.5mm	20mL Amber Curved Top Head Vial, Flat Bottom, 22.5*75.5mm	20mL Amber Curved Top Head Vial, Round Bottom, 22.5*75.5mm

20mm Curved Top Aluminum Caps and Septa

20mm Crimper and Decapper
